Spec Detail
Specifications
| Supply voltage type | DC |
| Number of digital inputs | 24 |
| Input type | PNP/NPN |
| Number of digital outputs | 16 |
| Output type | PNP |
| Program capacity | 20 K steps |
| Data memory capacity | 32 K words |
| Logic execution time | 0.10 µs |
| Communication port(s) | USB |
| Number of Ethernet ports | 0 |
| Number of USB ports | 1 |
| Number of RS-232 ports | 0 |
| Number of RS-485 ports | 0 |
| Communication option(s) | CAN, CompoBus/S Master, CompoBus/S Slave, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, Ethernet TCP/IP, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485 |
| Number of analog inputs | 4 |
| Number of analog outputs | 2 |
| Number of encoder input channels | 4 |
| Max. encoder input frequency | 100 kHz |
| Max. number of PTP axes | 4 |
| Max. pulse output frequency | 100 kHz |
| Function Block programming | |
| Battery-free memory backup | |
| Real-time clock | |
| Analogue option boards | |
| Max. number of analogue I/O channels | 62 |
| Max. number of local I/O points | 320 |
| Max. number of expansion units | 7 |
| Built-in auxiliary 24 VDC output | 0 mA |
| Operating temperature range | 0-55 °C |
| Product Height (unpacked) | 90 mm |
| Product Width (unpacked) | 150 mm |
| Product Depth (unpacked) | 85 mm |
| Product Weight (unpacked) | 600 g |
Application of PLC
PLC is widely used in the control fields of various production lines, such as the automotive industry, electronics industry, machinery manufacturing, etc. PLC can realize automatic control of various production processes on the production line, such as automatic assembly, processing, packaging, transportation, testing and other operations, improving production efficiency and reducing labor costs.
PLC can be used for robot control in automated production. Through PLC, the robot's motion control, feedback control, autonomous decision-making and other functions can be realized to improve production efficiency and production benefits.
Application of PLC
PLC can be used in the field of medical equipment control, such as surgical robots, medical instrument control, etc. For example, using PLC to control surgical robots can realize automatic operation, control and adjustment of surgical instruments, improve surgical accuracy and safety, and ensure surgical quality and patient safety.
PLC can be used in energy management, security monitoring, lighting control, building automation, etc. in intelligent building systems to achieve energy-saving, safe, and comfortable building environments.
